Stubby Plungers

Steel

Stubby plungers offer greater travel than ball plungers and less travel than standard plungers. These compact spring plungers provide considerable plunger travel and high end forces which are ideal for restricted space applications.

Typical Uses

  • Limited space
  • Indexing
  • Electrical contacts
  • Part positioning
  • With Thread Lock
  • Detents

Special Features

  • Case hardened plunger
  • Wear & corrosion resistance
  • Compact size
  • Allows some side loading
  • Intermediate travel
  • Screwdriver installation
Download the PDF
Stubby Plungers - Steel
Stubby Plungers - Steel
ANSI (Inch/American) Tables
Metric Tables
CAD Library

Stubby Plungers - Steel w/Steel Nose

Part No.End Force, (Lbs.)ABCDROHSCAD
CAD
With Thread Lock
With Thread LockInitialFinal
M50AM50AP1-1/24-3/48-320.4370.0520.070M50AM50AP
M50M50P1-1/24-3/48-360.4370.0520.070M50M50P
M52M52P1-3/46-1/410-320.4680.0650.093M52M52P
M54M54N3.010-1/21/4-200.5310.0780.119M54M54N
M56M56N3-3/415-1/25/16-180.5620.0840.135M56M56N
M58M58N4-1/218-1/23/8-160.6250.1100.186M58M58N
M60M60N5.028.01/2-130.7500.1510.248M60M60N
M62M62N7.050.05/8-111.0620.2150.310M62M62N

Stubby Plungers - Steel w/Stainless Steel Nose

Part No.End Force, (Lbs.)ABCDROHSCAD
CAD
With Thread Lock
With Thread LockInitialFinal
CM50ACM50AP1-1/24-3/48-320.4370.0520.070CM50ACM50AP
CM50CM50P1-1/24-3/48-360.4370.0520.070CM50CM50P
CM52CM52P1-3/46-1/410-320.4680.0650.093CM52CM52P
CM54CM54N3.010-1/21/4-200.5310.0780.119CM54CM54N
CM56CM56N3-3/415-1/25/16-180.5620.0840.135CM56CM56N
CM58CM58N4-1/218-1/23/8-160.6250.1100.186CM58CM58N
CM60CM60N5.028.01/2-130.7500.1510.248CM60CM60N
CM62CM62N7.050.05/8-111.0620.2150.310CM62CM62N

Light End Force Stubby Plungers - Steel

Part No.End Force, (Lbs.)ABCDROHSCAD
CAD
With Thread Lock
With Thread LockInitialFinal
M51AM51AP1/21-1/28-320.4370.0520.070M51AM51AP
M51M51P1/21-1/28-360.4370.0520.070M51M51P
M53M53P3/42-1/210-320.4680.0650.093M53M53P
M55M55N1.03-1/21/4-200.5310.0780.119M55M55N
M57M57N1-1/44.05/16-180.5620.0840.135M57M57N
M59M59N1-1/25.03/8-160.6250.1100.186M59M59N
M61M61N1-3/45-1/21/2-130.7500.1510.248M61M61N
M63M63N2.08-1/25/8-111.0620.2150.310M63M63N

Light End Force Stubby Plungers - Steel w/Stainless Steel Nose & w/ Thread Lock Element

Part No.End Force, (Lbs.)ABCDROHSCAD
CAD
With Thread Lock
With Thread LockInitialFinal
CM51ACM51AP1/21-1/28-320.4370.0520.070CM51ACM51AP
CM51CM51P1/21-1/28-360.4370.0520.070CM51CM51P
CM53CM53P3/42-1/210-320.4680.0650.093CM53CM53P
CM55CM55N1.03-1/21/4-200.5310.0780.119CM55CM55N
CM57CM57N1-1/44.05/16-180.5620.0840.135CM57CM57N
CM59CM59N1-1/25.03/8-160.6250.1100.186CM59CM59N
CM61CM61N1-3/45-1/21/2-130.7500.1510.248CM61CM61N
CM63CM63N2.08-1/25/8-111.0620.2150.310CM63CM63N





Stubby Plungers - Steel w/Steel Nose

Part No.End Force, NABCDROHSCAD
CAD
With Thread Lock
With Thread LockInitialFinal
MHM4MHM4P7.021.0M4 x 0.711.11.31.8MHM4MHM4P
MM4MM4P2.07.0M4 x 0.711.11.31.8MM4MM4P
MHM5MHM5P8.028.0M5 x 0.811.91.72.4MHM5MHM5P
MM5MM5P3.011.0M5 x 0.811.91.72.4MM5MM5P
MHM6MHM6P13.047.0M6 x 1013.52.03.0MHM6MHM6P
MM6MM6P4.016.0M6 x 1013.52.03.0MM6MM6P
MHM8MHM8P17.069.0M8 x 1.2514.32.13.4MHM8MHM8P
MM8MM8P6.018.0M8 x 1.2514.32.13.4MM8MM8P
MHM10MHM10P20.082.0M10 x 1.515.92.84.7MHM10MHM10P
MM10MM10P7.022.0M10 x 1.515.92.84.7MM10MM10P
MHM12MHM12P22.0125.0M12 x 1.7519.13.86.3MHM12MHM12P
MM12MM12P8.024.0M12 x 1.7519.13.86.3MM12MM12P
MHM16MHM16P31.0222.0M16 x 2.027.05.57.9MHM16MHM16P
MM16MM16P9.038.0M16 x 2.027.05.57.9MM16MM16P
